9 1/2" FM16053TU , Matrix Body PDC Bit , Drill Bit , Gas Well Drilling Bit
FM series
Matrix body PDC drill bit
* Medium soft to medium formation drilling
Products with optimized bit profile is designed for drilling medium soft to medium homogeneous formations.
* Gage protection
Composite gage protection and low torque design improved the rate of penetration.
* Hydraulic system
CFD hydraulic balance design results in better bit cleaning and cutting removal.
| Product Specifications | |||||||
| Bit Size (in.) | 6 | 8 1/2 | 9 1/2 | 11 5/8 | 12 1/4 | ||
| IADC Code | M233 | M223 | M223 | M223 | M223 | ||
| Number of Blades | 5 | 5 | 5 | 5 | 5 | ||
| Number of Nozzles | 5 | 6 | 6 | 6 | 8 | ||
| Total Number of Cutters | 20 | 27 | 31 | 42 | 45 | ||
| Primary Cutter Size(mm) | 13 | 16 | 16 | 19 | 19 | ||
| Standard Gauge Length | 70mm | 75mm | 70mm | 100mm | 120mm | ||
| API Reg. Pin Connex.(in.) | 3 1/2 | 4 1/2 | 6 5/8 | 6 5/8 | 6 5/8 | ||
| Recommended Operation Parameters | |||||||
| Bit Size (in.) | 6 | 8 1/2 | 9 1/2 | 11 5/8 | 12 1/4 | ||
| Hydraulic Flow Rate(L/s) | 25~35 | 25~35 | 25~35 | 44~60 | 44~60 | ||
| Hydraulic Flow Rate(Gpm) | 390~550 | 390~550 | 390~950 | 690~950 | 690~950 | ||
| Rotation Speed(Rpm) | 50~500 | 50~500 | 50~500 | 50~500 | 50~500 | ||
| WOB(KN) | 30~100 | 30~100 | 30~100 | 50~160 | 50~160 | ||
| WOB(KLbs) | 8~23 | 8~23 | 8~23 | 12~36 | 12~36 | ||
| Maximum WOB(KN) | 100 | 100 | 100 | 160 | 160 | ||
| Maximum WOB(KLbs) | 23 | 23 | 23 | 36 | 36 | ||
* Other types and sizes could be designed and manufactured according to the specific requirments.
|
|
